DIPLOMATE


Step 1: Find your parts
Step 2: Find a dealer

Exploded view drawing and parts list:DIPLOMAT

Make your selection...

Note that the quantities per item listed below are the standard quantities found in each appliance, not the number of items you need to order.
# Item # Description Availability QTY -
Item per
appliance
MSRP per item
Selection
1 AC06000 SILICONE AND 1/2" X 8' BLACK DOOR GASKET KIT In stock 1 $20.00
1 99998 DISCONTINUED
Out of stock
2 -
1 29001 4'' X 8 1/8'' X 1 1/4'' REFRATORY BRICK HD In stock 24 $7.00
1 45159 INSTRUCTION MANUAL FLAME
Out of stock
1 $15.00
1 AC05959 METALLIC BLACK STOVE PAINT - 342 g (12oz) AEROSOL In stock 1 $21.00
1 AC05970 CAST IRON DRAFT CONTROL WITH NUTS & BOLT In stock 1 $40.00
1 SE59012 AIR DEFLECTOR
Out of stock
1 $15.00
- AC05959 METALLIC BLACK STOVE PAINT - 342 g (12oz) AEROSOL 1 $21.00

...and


 :
